SEAFLO 31 Series DC Diaphragm Pump 12V 1.8GPM/7.0LPM
SEAFLO 31 Series DC Diaphragm Pump 12V 1.8GPM/7.0LPM
SKU:SFDP1-018-080-31
Low stock: 1 left
Couldn't load pickup availability
The 31-Series is a continuous-duty, on-demand positive displacement pump offering dependable performance for moderate water flow and high-pressure applications. With up to 1.8 gallons per minute capacity and the ability to self-prime up to 6 vertical feet, this 3-chamber diaphragm pump can even function with no water present without sustaining damage. Additionally, it features multi outlet ports for 1-2 3/8” (10 mm) connections at one time, as well as a built-in pressure switch that turns the pump on or off automatically as the fixture is used. Installing, servicing, and winterizing these pumps are straightforward tasks.
Feature
- 16AWG, 4.5" long Leads.
- Adjustable pressure switch.
- Continuous Duty and Run dry safe.
- Self priming capability.
- Continuous duty operation.
- 2 Year Warranty.
- Industry Standard mounting pattern.
- Meets or exceeds RoHS, SGS, and ISO standards.
Standard Configurations
- Model: SFDP1-018-080-31
- Voltage: 12V
- Open Flow: 1.8 GPM / 7.0 LPM
- Control Type: Switch
- Max Draw: 9.0 A
- Shut-off Pressure: 80 PSI / 5.5 BAR
- Valves: EPDM
- Diaphragm: Santoprene
- Ports: 3/8"-18 FNPT
- Wire Connections: 2-Pin/Leads
